NOVOFLEX MELAGRIP CABLE MARKERS
(Straight & Chevron Cut) :
A versatile range of Cable Markers made from high quality plasticised PVC. It's unique design gusset allows easy and quick fitting of markers on wires and cables without the aid of any special applicator or assembly tool. Available in straight cut and chevron cut. The Chevron cut (interlocking type) markers ensure simple, positive and accurate alignment of legends. These markers have excellent di-electric and tensile strength plus resistance to moisture, acids, alkalies, gasoline, most oils, alcohol etc.
Standard Colours : White or Yellow body marked black and also available on request 0 to 9 in international
Resistor Colour Code (IRCC).
Standard Markings : 0 to 9, A to Z, +, -, /, Blank.
Material : Flexible PVC.
Service Temperature Range : -40 degree Cent. To +85 degree Cent.
Cable Overall dia Range : 2.20mm. to 12.00mm.
Cable Size Range : 0.5 sq.mm. to 35 sq.mm.
------------------------------------------------
The Modern system of marking large cables
* Carrier Strips with Ovalgrip Cable Markers, provide a simple, fast and convenient means of identifying Cable bundles, large diameter cables, conduits, pipes and tubes by using Cab-lok Cable Ties.
* Carrier Strips available in three standard sizes in black colour as standard.
* Carrier Strip Part No. AT-1 & AT-3 holds upto ten & eighteen OG 85 Cable markers respectively and can be fixed by single or two cable ties having width upto 6mm.
* Carrier Strip Part No. AT-2 holds upto fourteen OG 85 Ovalgrip Cable marker and can be attached either by single Cable tie width upto 3mm or two cable ties having width upto 8mm.
* The systems can be used at the cable ends as well as at any intermittent position.
* Cab-lok Cable Ties upto 8mm width are available for cable diameter 106mm and thus by using Cablok Cable Ties, Ovalgrip Cable markers and carrier strips one can mark desired legends upto 106mm diameter cables, cable
bundles, conduits, pipes and tubes.
Spirowrap Harness Bands
